Desfire Magic Card Reader
Desfire Magic Card Reader
VIEW PDFDescription
- Read full 56 bits UID, Application & Files content of DesFire EV1 card
- Support 3DES & AES encrypted communication between the reader and card
- Support on-site Reader Configuration Card to change certain parameters
- Number pad use “touching sensor”, the latest technology and individual number backlit when touch
- Tamper protection
- Front plate customization and back lit design is available
- Door Bell feature
- A PIN can be set inside the card to authenticate with the reader so that “Card + PIN” mode can be implemented without relying on the controller
- “Touch” number pad does not carry any moving parts, which implies more durable
- Weather proof design with IP65 certificate
- Metal back plate allows the reader install on metal surface and back-to-back without affecting the read range
- Universal back plate allows the reader be installed on different size of gang box
- Non-drop bottom screw made servicing handier
- All input and output signals are protected against static charges
- Reverse power protection
- Stainless steel Security screw is an option
- All inputs are 12Vdc protected
| Specifications | ||
|---|---|---|
| Configuration | ||
| Re-configure Window | 5 seconds (Default) or Half an hour after power up | |
| Reader Output Format | CSN/UID 32bits, 34bits, 56bits (backward/forward), file content reading for programmed ID | |
| Wiegand Plus Width | Different choices to fit with different Controller’s requirements | |
| Keypad Output | Definable | |
| Buzzer Control | Reader & controller control (default) or controller control only | |
| LED/Back lit Control | Define different LED color response base on Green LED | |
| Technical Specifications | ||
| Typical Read Range | 2 – 3 cm | |
| Reader Standard Output | Wiegand (RS232 & RS485 optional) | |
| Standard Keypad Output | Wiegand with 4 bits burst | |
| Wiring Distance | 150m (22 AWG with shielded cable) | |
| Operating Specification | ||
| Operating Voltage | 10 – 15 VDC | |
| Operating Current | 150mA (max) | |
| Operating Temperature | -30◦C – 70◦C | |
| Case Material | PC + ABS | |
| Standard Color | Black | |
| Operating Humidity | 10% – 90% | |
