ESP -4104-P-4 Channel Smart 1U Network Video Recorder

ESP -4104-P-4 Channel Smart 1U Network Video Recorder



  • H.264+/H.264 codec decoding
  • Max 80Mbps Incoming Bandwidth
  • Up to 5MP Resolution for Preview and Playback
  • HDMI/VGA simultaneous video output
  • Support IPC UPnP, 4PoE ports
  • Support ANR technology to enhance the
  • storage reliability when the network break down
Main ProcessorDual-core embedded processor
Operating SystemEmbedded LINUX
Display Interface1 HDMI, 1 VGA
Resolution1920 × 1080, 1280 × 1024,
1280 × 720, 1024 × 768
Multi-screen Display1/4
OSDCamera title, Time, Video loss, Camera lock,
Motion detection, Recording
Recording CompressionH.264+/H.264/MJPEG
Recording Resolution5MP/ 4MP/ 3MP/1080P/1.3MP/720P
Record Rate80Mbps
Bit Rate16Kbps ~ 20Mbps Per Channel
Video DetectionMotion Detection, MD Zones: 396
(22 × 18), Video Loss and Camera Blank
Search ModeTime /Date, MD and Exact Search
(accurate to second), Smart search
IP Camera Input4 Channel
Playback FunctionPlay, Pause, Stop, Rewind, Fast play, Slow Play, Next File,
Previous File, Next Camera, Previous Camera, Full
Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode/td>USB Device/Network
USB2 USB Ports (2 USB2.0)
Alarm inputN/A
Relay OutputN/A
Network Interface1 RJ-45 Port (10/100Mbps)
Ethernet Port1 Independent 100Mbps Ethernet Port
Internal HDD1 SATA III Port, Up to 6 TB capacity for each HDD
Two-way Talk1 Channel Input, 1 Channel Output, RCA
Record ModeManual, Schedule (Regular, Continuous), MD (Video detection:
Motion Detection, Camera Blank, Video Loss), Stop
Max. User Access128 users
Smart PhoneiPhone, iPad, Android
Power SupplyDC48V/1.5A
Power Consumption<10W (Without HDD)
Dimensions of DeviceSmart 1U,
(8.1″ x 8.1″ x 1.8″)
Gross Weight1.5kg (without HDD)


Max 80Mbps Incoming Bandwidth Up to 5MP Resolution for Preview and Playback
