High Waterproof Ceiling Speaker Series

High Waterproof Ceiling Speaker Series

VIEW PDF

Features:

  • Full range speaker with back cover.
  • Water-resistant ceiling speaker
  • Sound quality is delicate and powerful.
  • It feature spring clip for easy speaker mounting to the ceiling.
  • Widely used in supermarkets, hotels, subways and so on.
  • The Dustproof Level : IP 4X

Specification

ModelCF-029CF-030YF-065YF-066
Rated Power3W-6W1.5W/3W/6W1.5W/3W
Input Model70V-100V
Sensitivity91dB±2dB
Frequency Response130-16KHz110-16KHz120-17KHz120-17KHz
MaterialABS HousingABS+ Iron Net
Speaker Unit4” X 16” X 14” X 1
Mounting Hole145mm180mmΦ120mm
Outer size180*65mm210*65mmΦ125 x 95mmΦ120 x 78mm
Weight0.5kg0.6kg0.58kg0.31kg

Description

It feature spring clip for easy speaker mounting to the ceiling.
