E3Bio carries out the matching of fingerprints on the panels. The FR Series of readers transmit fingerprint templates to E3Bio via RS-485 for fast and accurate matching with templates stored in a data-base. E3Bio controllers install easily on your network and support both TCP/IP and RS-485 communication. Auto-discovery tool allows setting and modification of network parameters directly and easily. E3Bio controller firmware can be upgraded in the field. Stores up to 3,000 fingerprint templates, 30,000 card users, and up to 100,000 events and transactions. Controller is backed up in real-time in on-board SD card. Data is preserved if power is lost. E3Bio continues to operate if network connection is interrupted. Along with relay contacts for controlling door locks, easily programmable auxiliary relays can be used for additional control and interface to lights, alarms, annunciators, intrusion detection panels, or even extra locking devices or gate controllers. E3Bio controllers come in three sizes to suit project needs and reduce the cost of unused capacity. 1-door, 2-door, and 4-door models can be mixed and matched in an optimized system architecture. Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxiliary Input/output Linkages are built into controller firmware.


  • Over-current protection, over-voltage protection, and reversal protection for the power supply and all of the input and output terminals
  • Reliable network system of controllers using either TCP/IP or RS-485 Serial
  • Supports different Wiegand formats, and connects to all readers as well as HID, Mifare, and generic ID card readers
  • Connects with a variety of electric locks, sensors, exit buttons, alarm devices, and indicators
  • Can be integrated with other security systems such as CCTV, Intrusion Detection, Fire Alarm Release, and elevator Control for total security system
  • Easy-to-use and intuitive programming by browser from client’s PC
  • Programming of special logic between doors is set up with simple pull down
    menus. No special scripts or code is required
  • Management software allows indication of real-time door status and remote commanding of door open/close state. Alarm conditions such as forced open and extended open alarms are reported
CPU 32bit 400MHz CPU
RAM 32M bits
User 30,000
Event Buffer 100,000
Power / Current DC 9.6V-14.4V DC, 1.5A
Reader Port 2ea (26/34bit Wiegand, 8bit Burst for PIN)
Communication RS485, TCP/IP
Baud Rate RS485 (9600-38400 baud)
Input Port 1ea (Auxiliary Input, Door Sensor, Request to
Output Port 1ea (1 Aux FORM-C relay output-SPDT 2A@30V
AC, 1 FORM-C relay output-SPDT 5A@36V DC
or 8A@30V AC)
LED Indicator Yes, LED indication for communication, power,
status and punch card
Dimension 160 x 106mm (L x W)
Temperature 0°C ~ 45°C
Operating Humidity 20% to 80%
